TDK Corporation DEA162450BT-1260B2

The DEA162450BT-1260B2 is a key component in the RF front-end of modern 5G communication systems. It operates within a specific frequency band to separate the desired signal from unwanted interference, ensuring clean and reliable data transmission and reception.

Built using TDK's advanced SAW technology, this filter offers a superior combination of electrical performance and mechanical robustness. Its extremely low insertion loss minimizes signal degradation, while its sharp roll-off characteristics provide excellent adjacent channel selectivity. These features are essential for maximizing the capacity and efficiency of 5G networks.

The DEA162450BT-1260B2 is available in a compact, hermetically sealed ceramic package, designed for high reliability and performance in the demanding conditions of 5G infrastructure. The package is optimized for surface-mount technology (SMT), facilitating automated assembly processes.

Typical SAW Filter Package (Example)

Note: Use the official TDK datasheet for exact dimensions, marking information, and recommended land pattern for PCB design.

The DEA162450BT-1260B2 is a two-port device with standard RF connections. The pin configuration is straightforward, consisting of an input port, an output port, and ground connections.

• RFIN: Radio Frequency Input Port
• RFOUT: Radio Frequency Output Port
• GND: Ground (Multiple pins for stability and heat dissipation)

For detailed pin assignments, electrical characteristics, and layout guidelines, please refer to the official TDK product datasheet.

For DEA162450BT-1260B2, "Equivalent" devices typically refer to other SAW or BAW (Bulk Acoustic Wave) filters from TDK or other manufacturers that operate in the same or similar frequency bands and meet comparable performance specifications. These equivalents may offer alternatives for specific design requirements or supply chain considerations. Examples of equivalent parts might include:

• DEA162450BT-xxxx - Variants with different performance optimizations or package options within the same product family.
• Other TDK 5G Filters - TDK offers a comprehensive portfolio of filters for various 5G bands.
• Competitor Equivalents - Filters from other leading RF component manufacturers designed for the same application space.

Always verify the exact electrical characteristics, package, and footprint of any equivalent device against your specific application requirements and consult the manufacturer's datasheet for confirmation.
